Neutrik NL4MMX Lockable 4-Pole SpeakON Barrel Adaptor

by Theatre Sound Supplies
Trusted by professionals across the industry
£8.39 - £8.39
£8.39
£8.39 - £8.39
£8.39
Description

The Neutrik NL4MMX Lockable 4-Pole SpeakON Adapter provides you with the ability to link together two cables with NL2F or NL4F SpeakON connectors, creating a reliable and robust cable extension. The NL4MMX can also be used to alter the gender of a female connector to a male connector when permanently locked onto your cable.

Specifications

  • Connection Type:¬†SpeakON
  • Gender:¬†Male
  • Contact Resistance:¬†Less than or equal to 3 m Ohms (after lifetime)
  • Dielectric Strength:¬†4 kVdc (peak)
  • Insulation Resistance:¬†Greater than 1 G Ohm (after dampheat)
  • Rated Current Per Contact:
    • 15 A RMS continuous
    • 30 A audio signal, duty cycle 50 percent
  • Rated Voltage:¬†250V (insulation)
  • Lifetime:¬†Greater than 5000 mating cycles
  • Locking Device:¬†Quick Lock
  • Contact Plating:¬†4 ¬µm Ag
  • Contacts:¬†Bronze (CuSn6)
  • Insert:¬†Polyamide (PA 6 30 percent GR)
  • Shell:¬†Polyamide (PA 6 30 percent GR)
  • Flammability:¬†UL 94 HB
  • Solderability:¬†Complies with IEC 68-2-20
  • Temperature Range:¬†-30 Degrees C to +80 Degrees C



ATTENTION: This SpeakON connector is NOT to be used as an AC mains or power supply connection.
